Ignition Switch With Keys - (No Fork Lock on this Type) -
OEM Ref. #584-82508. Fits: XS650 1976-77 (May adapt to other years)..
Note: Yamaha has made various versions of this switch and all are sold
under the same OEM part number. Ours does Not have a connector plug but wire leads with terminals (extra opposing terminals included with switch). You may have to fit this switch to match your bikes harness connections in the headlamp shell.
Key Position 1. Red wire in headlamp shell from main harness (+power feed from battery) goes to red Ignition switch wire.
Key Position 2. Power is fed out via 2 brown wires & 1 red wire with yellow
Key Position 3. Power is fed out via 2 blue wires (park position-only tail
light is on).
Part #12-4036 $16.95 Ea.
